Providers

The NodeTool provider system offers a unified interface for interacting with various AI service providers. This abstraction allows you to switch between different AI backends (OpenAI, Anthropic, Gemini, HuggingFace, etc.) without changing your workflow logic.

Overview

Providers in NodeTool act as adapters that translate between NodeTool’s internal formats and the specific API requirements of different AI services. The system supports multiple modalities:

Language Models (LLMs) - Text generation and chat completions
Image Generation - Text-to-image and image-to-image creation
Video Generation - Text-to-video and image-to-video synthesis
Text-to-Speech (TTS) - Convert text to natural speech audio
Automatic Speech Recognition (ASR) - Transcribe audio to text
3D Generation - Text-to-3D and image-to-3D model creation

To select a provider, pick a model in the node property panel. Providers are grouped under model families: OpenAI, Anthropic, Gemini, Hugging Face, Ollama, vLLM.

Architecture

Provider Capabilities

The capability system uses introspection to automatically detect which features a provider supports:

Capability	Description	Method
`GENERATE_MESSAGE`	Single message generation	`generate_message()`
`GENERATE_MESSAGES`	Streaming message generation	`generate_messages()`
`TEXT_TO_IMAGE`	Generate images from text	`text_to_image()`
`IMAGE_TO_IMAGE`	Transform images with text	`image_to_image()`
`TEXT_TO_VIDEO`	Generate videos from text	`text_to_video()`
`IMAGE_TO_VIDEO`	Animate images into videos	`image_to_video()`
`TEXT_TO_SPEECH`	Convert text to speech	`text_to_speech()`
`AUTOMATIC_SPEECH_RECOGNITION`	Transcribe audio to text	`automatic_speech_recognition()`

Available Providers

Language Model Providers

Provider	File	Streaming	Tool calls	Vision	Notes
OpenAI	`openai-provider.ts`	✅	✅	✅	Includes DALL-E, TTS, Whisper
Anthropic	`anthropic-provider.ts`	✅	✅	✅	JSON via tool use
Google Gemini	`gemini-provider.ts`	✅	✅	✅	File input via Blobs, Veo video
Ollama	`ollama-provider.ts`	✅	model-dependent	Base64	Local, no API key. `ollama pull` first
vLLM	`vllm-provider.ts`	✅	model-dependent	✅	OpenAI-compatible, self-hosted
HuggingFace	`huggingface-provider.ts`	✅	—	—	Hub models via FAL/Together/Replicate. See HuggingFace Integration
Groq	`groq-provider.ts`	✅	✅	—	Ultra-fast inference via Groq LPU
Mistral	`mistral-provider.ts`	✅	✅	—	Mistral & Mixtral models
Cerebras	`cerebras-provider.ts`	✅	✅	—	High-throughput Cerebras inference
OpenRouter	`openrouter-provider.ts`	✅	✅	model-dependent	300+ models via one key. Includes image generation
LM Studio	`lmstudio-provider.ts`	✅	model-dependent	model-dependent	Local LM Studio server (no API key needed)
Together AI	`together-provider.ts`	✅	✅	—	Open-weight model hosting
Moonshot (Kimi)	`moonshot-provider.ts`	✅	✅	—	Kimi coding plan — Anthropic-compatible endpoint

Video Generation Providers

Text-to-video and image-to-video providers available through the unified interface.

Provider	Capabilities	API Key
OpenAI Sora 2 Pro	T2V, I2V	`OPENAI_API_KEY`
Google Veo 3.1 (Gemini)	T2V, I2V, multi-image reference	`GEMINI_API_KEY`
MiniMax Hailuo 2.3	T2V, I2V	`MINIMAX_API_KEY`
xAI Grok Imagine	T2V, I2V, T2I	via kie.ai
Alibaba Wan 2.6	T2V, I2V, multi-shot	via kie.ai
Kling 2.6	T2V, I2V with audio	via kie.ai

Image Generation Providers

Provider	Access
Black Forest Labs FLUX.2	via HuggingFace or direct API
Google Nano Banana Pro	`GEMINI_API_KEY` or via kie.ai
OpenAI DALL-E 2/3	`OPENAI_API_KEY`

3D Generation Providers

Provider	Capabilities	API Key
Hunyuan3D V2/3.0	T2-3D, I2-3D	`HUNYUAN3D_API_KEY`
Trellis 2	T2-3D, I2-3D	`TRELLIS_API_KEY`
TripoSR	I2-3D	`TRIPO_API_KEY`
Shap-E	T2-3D, I2-3D	`SHAP_E_API_KEY`
Point-E	T2-3D	`POINT_E_API_KEY`
Meshy AI	T2-3D, I2-3D	`MESHY_API_KEY`
Rodin AI	T2-3D, I2-3D	`RODIN_API_KEY`

Use the HuggingFace 3D nodes (HFTextTo3D, HFImageTo3D) or the generic nodes (nodetool.3d.TextTo3D, nodetool.3d.ImageTo3D) to switch providers.

Multi-Provider Aggregators

kie.ai — KIE_API_KEY. Unified access to multiple models via a single API. Recommended for providers without direct NodeTool API key support (xAI Grok Imagine, Alibaba Wan 2.6, Kling 2.6, FLUX.2, Nano Banana Pro).

Generic Nodes: Provider-Agnostic Workflows

Generic nodes in the nodetool.* namespace accept a model parameter and route to the matching provider. Use these to switch providers without rewiring the graph.

Node	Switch between
`nodetool.agents.Agent`	OpenAI, Anthropic, Gemini, Ollama, any LLM
`nodetool.image.TextToImage`	FLUX.2, Nano Banana Pro, DALL-E, HuggingFace, ComfyUI, MLX
`nodetool.image.ImageToImage`	HuggingFace, local servers, cloud services
`nodetool.video.TextToVideo`	Sora 2 Pro, Veo 3.1, Grok Imagine, Wan 2.6, Hailuo 2.3, Kling 2.6, HuggingFace
`nodetool.video.ImageToVideo`	Sora 2 Pro, Veo 3.1, Grok Imagine, Wan 2.6, Hailuo 2.3, Kling 2.6, Stability AI
`nodetool.3d.TextTo3D`	Hunyuan3D, Trellis 2, Meshy AI, Rodin AI, Shap-E, Point-E
`nodetool.3d.ImageTo3D`	Hunyuan3D, Trellis 2, TripoSR, Meshy AI, Rodin AI, Shap-E
`nodetool.audio.TextToSpeech`	OpenAI TTS, ElevenLabs, local TTS
`nodetool.text.AutomaticSpeechRecognition`	OpenAI Whisper, HuggingFace, local ASR

Select the node, open the model dropdown in the properties panel, and pick any available model. The node routes automatically.

Fall back to different providers if one is unavailable
Optimize costs by mixing providers in one workflow

Provider Parameter Mapping

Generic nodes map parameters to provider-specific formats:

TextToImage mapping:

const params: TextToImageParams = {
  prompt: "...",             // -> All providers
  negative_prompt: "...",    // -> HuggingFace, Gemini (ignored by DALL-E)
  width: 1024,              // -> HuggingFace (mapped to size for DALL-E)
  height: 1024,             // -> HuggingFace (mapped to size for DALL-E)
  guidance_scale: 7.5,      // -> HuggingFace (not used by DALL-E)
  num_inference_steps: 30,  // -> HuggingFace (not used by DALL-E)
  seed: 42,                 // -> HuggingFace (not supported by DALL-E)
  scheduler: "...",          // -> HuggingFace-specific
};

If a provider does not support a parameter (e.g., negative prompt for DALL-E), NodeTool automatically ignores or remaps it.

TextToVideo mapping:

const params: TextToVideoParams = {
  prompt: "...",           // -> All providers
  aspect_ratio: "16:9",   // -> Provider-specific interpretation
  resolution: "720p",     // -> Provider-specific interpretation
  num_frames: 60,         // -> Provider-specific (duration mapping)
  guidance_scale: 7.5,    // -> Provider-specific
};

Best Practices

Prefer generic nodes so you can swap providers without rewiring.
Use provider-specific nodes only for unique features (e.g. Claude thinking mode, OpenAI vision detail).
Test cheaper or faster models during development, switch to premium models for production.

Provider Configuration Reference

Environment Variables by Provider

OpenAI	`OPENAI_API_KEY`	-
Anthropic	`ANTHROPIC_API_KEY`	-
Gemini	`GEMINI_API_KEY`	-
HuggingFace	`HF_TOKEN`	-
Ollama	-	`OLLAMA_API_URL`
vLLM	-	`VLLM_BASE_URL`, `VLLM_API_KEY`
Replicate	`REPLICATE_API_TOKEN`	-
FAL	`FAL_API_KEY`	-
ElevenLabs	`ELEVENLABS_API_KEY`	-
Groq	`GROQ_API_KEY`	-
Mistral	`MISTRAL_API_KEY`	-
Cerebras	`CEREBRAS_API_KEY`	-
OpenRouter	`OPENROUTER_API_KEY`	-
LM Studio	`LMSTUDIO_API_KEY` (optional)	`LMSTUDIO_API_URL` (default `http://127.0.0.1:1234`)
Together AI	`TOGETHER_API_KEY`	-
Moonshot (Kimi)	`KIMI_API_KEY`	-

Getting API Keys

OpenAI: https://platform.openai.com/api-keys
Anthropic: https://console.anthropic.com/settings/keys
Google Gemini: https://ai.google.dev/
HuggingFace: https://huggingface.co/settings/tokens
Replicate: https://replicate.com/account/api-tokens
FAL: https://fal.ai/dashboard/keys
ElevenLabs: https://elevenlabs.io/app/settings/api-keys
Groq: https://console.groq.com/keys
Mistral: https://console.mistral.ai/api-keys
Cerebras: https://cloud.cerebras.ai/
OpenRouter: https://openrouter.ai/keys
Together AI: https://api.together.xyz/settings/api-keys
Moonshot (Kimi): https://platform.moonshot.cn/console/api-keys
LM Studio: No key needed — download from https://lmstudio.ai and start a local server

3D Provider	Required Variables
Hunyuan3D	`HUNYUAN3D_API_KEY`
Trellis	`TRELLIS_API_KEY`
TripoSR	`TRIPO_API_KEY`
Point-E	`POINT_E_API_KEY`
Meshy AI	`MESHY_API_KEY`
Rodin AI	`RODIN_API_KEY`

Provider Development

To add a new provider:

Create provider class in packages/runtime/src/providers/

import { BaseProvider } from "@nodetool/runtime";
import { registerProvider } from "@nodetool/runtime";
import type { Message, LanguageModel, ProviderId } from "@nodetool/runtime";

export class YourProvider extends BaseProvider {
  private apiKey: string;

  constructor(kwargs: Record<string, unknown> = {}) {
    super("your_provider" as ProviderId);
    this.apiKey =
      (kwargs.YOUR_PROVIDER_API_KEY as string) ??
      process.env.YOUR_PROVIDER_API_KEY ??
      "";
  }

  static requiredSecrets(): string[] {
    return ["YOUR_PROVIDER_API_KEY"];
  }

  async *generateMessages(
    messages: Message[],
    model: string
  ): AsyncIterable<ProviderStreamItem> {
    // Implement streaming message generation
  }

  async getAvailableLanguageModels(): Promise<LanguageModel[]> {
    return [];
  }
}

Register in packages/runtime/src/providers/index.ts

import { YourProvider } from "./your-provider.js";
export { YourProvider };

Register the provider in packages/runtime/src/providers/provider-registry.ts

registerProvider("your_provider", YourProvider, {
  YOUR_PROVIDER_API_KEY: process.env.YOUR_PROVIDER_API_KEY,
});

Add provider ID to the ProviderId union in packages/runtime/src/providers/types.ts
Add configuration to .env.example
Document in this file

Testing Providers

Test your provider implementation:

vitest run tests/providers/your-provider.test.ts

Example test structure:

import { describe, it, expect } from "vitest";
import { getProvider } from "@nodetool/runtime";
import type { Message } from "@nodetool/runtime";

describe("YourProvider", () => {
  it("should generate a message", async () => {
    const provider = await getProvider("your_provider");
    const messages: Message[] = [{ role: "user", content: "Hello" }];

    const chunks: ProviderStreamItem[] = [];
    for await (const chunk of provider.generateMessages(messages, "your-model-id")) {
      chunks.push(chunk);
    }

    expect(chunks.length).toBeGreaterThan(0);
  });
});
